Vallox > Vallox 90 MC
Vallox 90 MC
Vallox 90 MC
Production ends on 31.12.2021
Annual efficiency (%)
74
Temperature efficiency of heat recovery (%)
83.4
SEC average climate
-30.74 kWh/m²a
Reference airflow rate
0.048 m³/s
Specific power input (SPI)
0.4 W/(m³/h)
Specific Fan Power (SFP)
1.44 kW/(m³/s)
Maximum extract airflow @ 100 Pa
85 l/s
Maximum supply airflow @ 100 Pa
70 l/s
Maximum supply airflow EcoDesign
252 m³/h
Duct outlets pcs
4
Duct outlet mm
125 mm
Product depth mm
361
Product width mm
597
Product height mm
689
Mounting place
Wall
Remote monitoring options
External voltage message 0-10 VDC
Extract air fan power consumption
0.119 kW
Supply air fan power consumption
0.119 kW
Sound power level
42 dB
Cell type
Cross-counter flow cell
Cell
Aluminium
HRU cell bypass
Automatic heat recovery bypass
Defrosting method
MC defrosting automatics with supply air fan stop
Post-heating
Electrical resistor, 900 W
