Vallox Exxeo

Vallox has revised its roof fan range

The variety of sizes and control methods, along with the elegant design, make Vallox Exxeo roof fans an excellent choice for any location.

Seven roof fans of different sizes
Models with three different control methods
Elegant design, sound-dampening enclosure and excellent weather-resistance

Modern elegant roof fan range with three different control methods

Vallox is introducing the new Vallox Exxeo roof fan series featuring seven sizes and three different control methods.

The seven roof fans in the Vallox Exxeo range with different air volumes are called Vallox Exxeo 150, 300, 700, 1400, 2000, 2500 and 4100. The most suitable model is chosen according to the required air volume: the air flows of the smallest roof fan in the range, Vallox Exxeo 150, and the largest, Vallox Exxeo 4100, are 150 dm3/s and 4,100 dm3/s, respectively, with a static pressure loss of 150 Pa.

Vallox Exxeo range has models with three different control methods: the versatile basic model Vallox Exxeo, the Vallox Exxeo DPC (Differential Pressure Control) model equipped with an integrated differential pressure transmitter and the Vallox Exxeo DS (Dual Speed) model designed for renovation projects.

Features of the Vallox Exxeo roof fans

Design is based on the views of customers

The new modern design of the Vallox Exxeo roof fan range is based on the views of architects and our customers. (Target group survey concerning the appearance of roof fans 01/2022.)

The roof fan may be painted

The roof fan may be painted in the factory with a tone included in the RAL colour chart for a perfect match with the colour of the roof, for instance.

Excellent weather-resistance

The zinc-magnesium coating protects the sheet metal against corrosion (environmental impact category C4).

The optional paint coating provides the roof fan surface with an additional layer of protection (environmental impact category C5). (Meets the requirements of the standard EN ISO 12944-2.)

Low sound level

The sound level of the fans is considerably lower than before, thanks to the sound-dampening elements in the side panels.

* Compared to previous Vallox roof fans.

Control equipment is integrated in the unit

All the control equipment is integrated within the roof fan.

The unit is delivered with the safety switch installed and cabled.

The tilting part enables easy maintenance

The tilting part enables turning the roof fan to the side during maintenance. The sealed tilting part also efficiently seals the fan against the roof penetration.

The duct stays clean and dry

The structure of the unit leads rainwater to the side, preventing it from entering the duct. The perforated roof panel protects the fan against leaves and other loose rubbish.
